LN88D is suitable for slitting of fine wool fabrics, chemical fiber filament fabrics, colored fabrics, silk fabrics, towel fabrics, and special industrial fabrics. It can be used as pre-weaving equipment for water jet loom, air jet loom, rapier loom, Projectile loom and other shuttleless looms. It is an ideal product for the company’s export to replace the imported sectional warping machine.

1. The axial displacement of the warping operation table is controlled by the high-precision servo motor to control the starting position and the positioning of the bar is automatically completed once.

2. Warping console can automatically radial displacement. It is controlled by an independent stepper motor so that the fixed width 3A and the forming yarn surface are maintained at equal distances and the distance can be arbitrarily set.

3. Application of new technology of AC variable frequency speed control by computer control to achieve stepless adjustment to maintain constant speed winding and unwinding of the yarn on the drum.

4. The oil pressure device integrated with a special machine, electricity, liquid, and gas generates oil pressure to push the caliper brake to complete the warping brake. Inverted shaft tension control adopts external steel belt damping method to eliminate the noise and tension unevenness caused by traditional clamp damping (automatic control system with pressure display and pressure size protection control tension unevenness)

5. Adopt advanced technologies such as computers and PLCs, and have the functions of total length, total length, strip count, and end-memory functions, full-length stop, full-length stop, and end-stop.

6. The human-machine interface of the large-screen touch screen is clearly displayed, has a large amount of information, and is easy to operate.

7. The main body of the main drum is fixed on the ground rail by a servo motor to control the moving splitter 3A frame and the creel stand. The warp strips are always in a straight line during the warping process and the yarn tension is kept constant.

8. 1:6.3 Fixed cone steel High-strength large drum and high-precision servo motor warping console can meet almost all varieties of warping process.

9. Both the reverse shaft speed and the inverted shaft length can reach the speed change tension, and the reverse shaft cannot operate when the tension force requirement is not reached. And equipped with speed sensor, is the product to achieve higher technological requirements.

10. Optional Two Types of Shaft Reversing Machines Overall Removable Shaft Shafting Machines One Shaft Shafting Machine can be combined with multiple warping heads with optional wax (oil) and weaving shaft pressurizing devices. The fixed shaft reversing machine is simple and easy to operate. With a variety of forms of creel to meet the requirements of different varieties of technology. Spindle spacing, spindle number can be specially configured according to user needs.

11. The optional tensioners for this machine include three-column adjustable tensioners, two-column fine-tuning tensioners, and single-column tensioners.

12. This machine is also equipped with a broken-yarn stop device and static eliminator.

1. Effective Reed Space	2300一5500(mm)( Special specifications can be customized)	Cone angle	7.1250
   Beam Pipe Diameter	<1000(mm)(Basic model)	Guide wire speed	0.001一9.999(mm/r)(step less)
   Warping Speed	0一600(m/min)	Guide bar following precision	0.02%
   Rewind Speed	0一150(m/min)	Fixed amplitude and roller distance	Adjustable
   Constant line speed accuracy	士2%	Starting point of cone	Automatic
   Braking distance	<2(m)speed 300m/min )	Guide bar positioning	Automatic
   Big drum diameter	<1026(N)	Warping trip width setting range	0.1一999.9(min)( Not more than the length of the guide roller)
   Cone length	1310(mm)
